Salsbury Surface Mounted 4C Horizontal Mailbox Unit (Includes 3706D-CAFP Mailbox, 3806D-ALM Enclosure and Master Commercial Locks) - 6 Door High Unit (24 1/2 Inches) - Double Column - Custom Unit - Aluminum - Front Loading - Private Access

Model # 3806D-CAFP

Size: 31.75" W x 24.5" H x 17" D

Weight: 255 lbs

More Information

Salsbury 3800 Series Surface Mounted 4C Horizontal Mailboxes - Front Loading - Private Access

Features

Surface Mounted 4C Horizontal Mailboxes include a 4C horizontal mailbox unit, a matching surface mounted enclosure and commercial master lock(s) - minor assembly required
Provide a convenient means of installing 4C horizontal mailboxes in locations where walls are not deep enough for a recessed mounted installation
Ideal for colleges, schools, private postal centers, corporate mail centers, military bases, government agencies and many other applications
For indoor or outdoor use
Constructed of heavy duty aluminum and stainless steel hardware
Standard height units feature a durable powder coated finish available in aluminum, bronze, sandstone and black
Accessed from the front through 1 or 2 easy opening master door panels
Doors include a heavy duty cam lock with a dust/rain shield and 3 keys
MB1 doors are 3-1/4" H x 12-3/4” W, MB2 doors are 6-3/4" H x 12-3/4” W, MB3 doors are 10-1/4" H x 12-3/4” W and MB4 doors are 13-3/4" H x 12-3/4” W
Standard height units are available in four (4) popular heights – 6 Door High, 10 Door High, 11 Door High and Maximum Height - and a variety of configurations to meet your requirements
Custom units are available in additional configurations and colors
Available in configurations that are 1 door wide (single column) and 2 doors wide (double column)
Fully integrated and stand-alone parcel lockers are available in varying sizes: PL3 (10-1/4" H), PL4 (13-3/4" H), PL4.5 (15-1/2" H), PL5 (17-1/4" H) and PL6 (20-3/4" H)
Most units include a compartment for outgoing mail collection and is labeled “Outgoing Mail”
Outgoing mail compartment includes the master commercial lock access door (lock included) and cannot be used for mail distribution
Outgoing mail compartment includes a 11-3/4” W x 3/4” H mail slot and weather protection hood
Include master commercial lock(s) – with (2) keys
ADA height compliant units available - ADA compliance guidelines
Salsbury Industries is ISO 9001:2015 certified and has excelled in the field of manufacturing since 1936

Options

Custom engraved placards
Custom engraved doors - regular
Custom engraved doors - black filled
Combination Locks
Plexiglass windows
Mail slots
Replacement locks
Additional keys
Key blanks
Outgoing mail slot plug kit

Downloads

Videos

Surface Mounted 4C Horizontal Mailbox Video
Installation Video – Surface Mounted 4C Mailboxes
Installation Video – Tenant Lock Replacement
Installation Video – Tenant Door Replacement
Installation Video – Locating Tenant Keys

Salsbury Surface Mounted 4C Horizontal Mailbox Unit (Includes 3706D-CAFP Mailbox, 3806D-ALM Enclosure and Master Commercial Locks) - 6 Door High Unit (24 1/2 Inches) - Double Column - Custom Unit - Aluminum - Front Loading - Private Access
