Salsbury Surface Mounted 4C Horizontal Mailbox Unit (Includes 3716S-CCFU Mailbox and 3816S-CST Enclosure) - Maximum Height Unit (57 3/4 Inches) - Single Column - Custom Unit - Custom Color - Front Loading - USPS Access

Model # 3816S-CCFU

17.75" W x 57.75" H x 17" D
140 lbs


More Information

Salsbury 3800 Series Surface Mounted 4C Horizontal Mailboxes - U.S.P.S. Access

Features

  • Surface Mounted 4C Horizontal Mailboxes include a U.S.P.S. approved 4C horizontal mailbox unit and a matching surface mounted enclosure - minor assembly required
  • Provide a convenient means of installing 4C horizontal mailboxes in locations where walls are not deep enough for a recessed mounted installation
  • Ideal for apartments, commercial buildings and residential developments
  • For indoor or outdoor use
  • Constructed of heavy duty aluminum and stainless steel hardware
  • Feature a durable powder coated finish
  • Accessed from the front through 1 or 2 easy opening master door panels
  • Doors include a heavy duty cam lock with a dust/rain shield and 3 keys
  • MB1 doors are 3-1/4" H x 13-1/4" W, MB2 doors are 6-3/4" H x 13-1/4" W, MB3 doors are 10-1/4" H x 13-1/4" W and MB4 doors are 13-3/4" H x 13-1/4" W
  • Available in five (5) MB1 equivalent door high units to fifteen (15) MB1 equivalent door high units, plus our popular maximum height units (57-7/8”H)
  • Available in configurations that are 1 door wide (single column) and 2 doors wide (double column)
  • U.S.P.S. standard 4C requires a minimum of 1 parcel locker for every 10 tenant compartments
  • Parcel lockers must be a minimum of 15" H to meet the 1:10 ratio. Once this ratio has been met, smaller parcel lockers may also be added
  • Fully integrated and stand-alone parcel lockers are available in varying sizes: PL3 (10-1/4" H), PL4 (13-3/4" H), PL4.5 (15-1/2" H), PL5 (17-1/4" H) and PL6 (20-3/4" H)
  • Most units include a compartment for outgoing mail collection and is labeled “Outgoing Mail”
  • Outgoing mail compartment / carrier access door includes the U.S.P.S. master lock access door (lock installed by the U.S.P.S.) and cannot be used for mail distribution
  • Outgoing mail compartment includes a 10-3/4" W x 3/4" H mail slot and weather protection hood
  • ADA height compliant units available - ADA compliance guidelines
  • Salsbury Industries is an ISO 9001:2015 certified company and has excelled in the field of manufacturing since 1936

Options

  • Custom engraved placards
  • Custom engraved doors - regular
  • Custom engraved doors - black filled
  • Replacement locks
  • Additional keys
  • Key blanks
  • Tenant parcel locker lock
  • Outgoing mail slot plug kit

Downloads

Videos

  • Surface Mounted 4C Horizontal Mailbox Video
  • Installation Video – Surface Mounted 4C Mailboxes
  • Installation Video – Tenant Lock Replacement
  • Installation Video – Tenant Door Replacement
  • Installation Video – Locating Tenant Keys
